Metal Fabrication: Used in metal fabrication shops to uncoil steel for cutting, bending, and forming operations.
Automotive Industry: Essential in the production of automotive parts where steel sheets are required.
Construction: Used in the construction industry for preparing steel sheets for roofing, siding, and structural components.
Appliance Manufacturing: Utilized in the production of household appliances that require steel components.
Pipe and Tube Manufacturing: Used to uncoil steel for the production of pipes and tubes.
Capacity: It can handle the steel coils up to 3 tons in weight.
Coil Width: Can accommodate coils of various widths, depending on the specific model and configuration.
Motorized or Manual: The decoiler can be devided to three types, one is full manual, that means mechanical expanding and passively releasing without any power; one is with mechanical expanding and then electric motor releasing and third one is full automatic which expanding by hydraulic station and releasing the coil by electric motor.
Safety Features: For electric motor releasing decoilers, there's emergency stop button which can stop the decoiler running while something urgent happens.
No | Item | Parameter | Remark |
1 | Capacity | 3T | |
2 | ID of the Coil | φ508mm/610mm | |
3 | Max. OD of Coil | Φ1200mm | |
4 | Width of Coil | Max.400/600mm | |
5 | Speed of Decoiling | Min.35m/min | Electric Decoiler |
6 | Power Source | 380V/3PH/50HZ | Customize |
