Smartech Machinery corrugated metal sheet roll former is widely used in the industry. Corrugated panel is a timeless panel with a long history of proven. The panel is utilized for projects on schools, supermarkets and shopping malls. The corrugated profile can be used as roofing, wall, siding and fencing.
Frame is a welded construction and made of heavy duty steel.
Chain driven with electrical motors, double-rowed chains.
Forming rolls with hardness HRC48-52
Each forming roll is attached to the shaft by a keyway. The spacers between the forming rolls are partly fixed by a keyway and partly free rotating.
Adjustable stations.
Advanced software and an easy-to-use screen interface.
| No | Item | Parameter | Remark | |
| 1 | Suitable Material | Type | PPGI | |
| Width(mm) | 1250 | customize | ||
| Thickness(mm) | 0.4-0.7 | |||
| Yield Strength(Mpa) | 230-300 | customize | ||
| 2 | Forming Speed(m/min) | 20/30/40/50 | customize | |
| 3 | Roller Material | No.45 steel with Chromeplate | Up to buyer | |
| 4 | Roller Shaft Diameter | 80 | customize | |
| 5 | Cutting Model | Hydraulic/Electric Cutting | ||
| 6 | Power source | Type | 380V/3PH/50HZ | Up to buyer |
| Total Power | According to actual design | |||
